Model: mini-140

Feature:

● MMA/LIFT-TIG 2 in 1

● Latest digital technology, , precise control and enhanced performance

● Compact design, portable and light weight, easy to use (2.3Kg)

● Include ARC-START, ARC-FORCE, Anti-sticking, VRD selections.

● Dual voltage is workable (110V/220V)

Parameter:

Input Voltage: AC230V±15％

Frequency: 50/60 Hz

Input Capacity: 4.9KVA

No-load Voltage: 56V

Current Range:  20-140A

Rated Duty Cycle:  60%

Insulation Class:  F

Protection Degree:  IP23

Packing Size: 300×150×180mm

Gross Weight: 2.3KGS

Max Real current:

MMA: 140A

LIFT-TIG: 140A
